BodyCAP Core Capsules

World-class physiological data monitoring that makes a difference

eCelsius capsules from BodyCAP allow continuous core body temperature monitoring for your research.

Multiparameter data analysis

Analyse multiple measurements at one time with the Equivital solution, including core temperature, heart rate, respiration rate and skin temperature.

Multi subject monitoring

Capture core temperature data for up to 8 subjects at one time with the dedicated Equivital eViewer Performance monitor. Data is stored on the capsule and buffered when in close proximity to the monitor.

Easy data extraction

Data is downloaded in one file for all the parameters, offering fast and efficient data export and subsequent analysis in eqManager.

Equivital TnR and eCelsius working together

  • Weight: 1.7g
  • Size: 17.7mm x 8.9mm
  • Sampling period: 30s, 1min, 2min
  • Accuracy: 0.2°C
  • Calibration range: 25°C to 45°C
  • FIFO memory: 2000 data capacity
  • Data transfer: RF transmission (433 – 434MHz)
  • Communication range: 1-3m (environment and patient dependent)
  • Long battery life – up to 20 days from activation
  • Shelf-life: 2 years from date of manufacture
  • View real-time data for 8 subjects at once
  • Data is stored on the core pill and buffered when the Equivital eViewer Performance monitor is in close proximity
  • Simple to use, log, transmit and export data using eqManager software
  • Available for global distribution
  • Works seamlessly with eqManager for easy data analysis
  • Easy integration so you can access your data faster
  • Download your core capsule datasets using eqManager
  • Ability to merge SEM and core capsule(s) datasets
  • Provides an optimised user experience for easy data analysis
  • Data can be extracted in CSV and Excel

The Equivital sales team are currently taking orders for the eCelsius capsules.  The average lead time is 4 weeks. We have global distribution partners making it easy for you to order locally and are also able to ship directly from head office.
